Experience a finished product like never before. A masterpiece of engineering, this edgebander is packed with features to make your job easier. The exceptionally steady and stable CBC.T platform uses a stainless-steel mono-block base. Simply lift the protection hood to access all operating components. A friction-free worktable feeds panels with high-precision as rollers move the panels through effortlessly and smoothly. Panel processing is fully automated and synchronized, while maintaining manual adjustments and mechanical readouts for reference.
Features:
- Machine frame made out of steel, single block base with superior stability.
- Anodized aluminum out-feed fence.
- Automatic Panel Feed System
- Dual Pressure rollers
- Melamine, PVC, ABS, PP, Veneer and Laminate
- Pre-Heated In-feed Fence
- Individually adjustable Flush Trimming
- Digital Temperature Control
- Front and back-end Trimming
- Top and Bottom Flush Trimming
- Dual Buffing Unit
- Push button Control panel
- Extendable Panel Support Rail
Specifications:
Automatic Feeding speed: 16ft/MIN or 5M/MIN
Panel thickness Min/Max: 31/64" - 1 3/4" or 12 - 45 MM
Edgebanding thickness: 0.0157" - 0.118" or 0.4 - 3 MM
Glue Pot Capacity: 2 Lbs or 1 kg
Max Edgebanding Height: 2" or 50 MM
Minimum panel width: 4 3/4" or 120 MM
Minimum panel length: 9 7/16" or 240 MM
Extendable Panel Support Rail Length: 78 21/32" or 1998 MM
Extension table Max Width: 12" or 310 MM
Size of Dust Collector Ports (2): 4" or 100 MM
Minimum Dust Collection Requirements: 700 CFM or 20M/MIN
Air Pressure Requirement: 6 SCFM @ 100 PSI or 7 kg/cm2
Edgebanding coil Support Diameter: 31 1/2" or 820 MM
Recommend Glue Temperature Range: 356°F - 410°F or 180°C - 210°C
Glue Type Pellet - Granulated Hot-Melt Pellet
Max. machine dimensions (LxWxH): 112"x 63"x 51" or 2844 x 1600 x 1295 MM
Machine weight: 849 LBS or 385 KGS
Shipping dimensions (LxWxH): 86" x 36" x 57" or 2184 x 914 x 1448 MM
Shipping weight: 1025 Lbs or 465 Kgs
Electrical Specifications:
Electrical Requirement: 1 Phase 220V 30 Amps 60 Hz
Conveyer Motor: 3/4HP(0.55KW)
Flush Trimmer Motor: 3/4HP(0.55KW)
End Trimmer Motor: 1/4HP(0.18KW)
Glue Spindle Motor: 1/3HP(0.25KW)
Top Buffing Motor: 1/4HP(0.18KW)
Bottom Buffing Motor: 1/4HP(0.18KW)
Sound Rating: 80 dB
